E-BOX series, the new generation LFP battery for home energy storage system. It provides safe,well-designed and high-performance standard LFP battery pack for you. The battery pack is compact, easy to install, free of maintenance, and could be deployed to the building block of energy storage system by being assembled in parallel. It is widely applied in home applications, small commercial and industrial energy storage system as well as Telecom stations.

Technical Specifications

Battery Model E-BOX-48100R
Chemistry LFP
Nominal Voltage 51.2V
Nominal Capacity 100Ah
Unit Dimension L440mm*W620mm*H117mm(2.6U)
Unit Weight 51kg
Standard Charge Current 50A
Maximum Charge Current 50A
Standard Discharge 50A
Maximum Discharge 50A
Round-Trip Efficiency ≥95%
Communication Protocol RS232, RS486, CAN
Cycle Life ≥6000 cycles
Calendar Life ≥10 years
Operating Temperature -10~50℃
Connect Style Parallel


1. CE certificate


Compatible inverter list:

European brands:

Victron Energy /

Phocos /


Chinese brands:

Growatt /

Kelong /

Goodwe /

Sermatec /

Voltronic Power /

LuxPower /

Megarevo /

Solis /

TBB Power /
